Features&advantages
1 Reliable operation of highprecision: New type of high speed digital signal processor,
2 Save test time: A host can control morethan one test furnace at the same time for multiple sample test
3 Automatic: Detection, open, ignition,alarm, cooling, printing, and automatically complete the whole e*perimentprocess
4 No air electric ignition mode, automaticignition
5 Detect atmosphericpressure and correct test results automatically
6 Use a newly developed high-powerhigh-frequency switching power supply heating technology, high heatingefficiency. Using adaptive PID control algorithm automatically adjusts theheating curve.
7 When the temperature is too high,automatically stop working, detection and alarm
8 Thermal micro printer, makes printingmore beautiful and more quickly, with functions of offline print
9 Historical record with a time stamp,store up to 255
10 Centuries calendar clock withtemperature compensation, accurate time, automatically recordsthe measuring date and time, in power-down state may run for morethan 10 years;
11 large 320*240 screen graphic LCDdisplay, rich content
12 touch screen buttons, convenientoperation and intuitive
13 Built-in multiple standards to choosefrom
Range | indoor temperature—400℃ |
Repeatability | 0.1℃ |
Accuracy | 0.5% |
Temperature Probe | Platinum resistance (PT100) |
Flash Fire sensors | ion detection |
Power | < 500W |
Rate of Temperature Increase | conform to the standards such as gb, the United States, the European Union |
Dimension | host: 190*260*285 (mm) |
furnace: 280*260*285(mm) | |
Weight | 18kg |
Environment temperature
|
10~40℃
|
